Optima Hardware Annunciator
Optima AP-400
Alarm Panel
Real-Time Network Vision. Zero-Latency Local Command.
Line-of-Sight Situational Awareness
Edge Annunciation
In modern industrial and telecommunications environments, a single unaddressed network fault can trigger an escalating cascade of downtime. The Optima AP-400 is a rugged, edge-deployed hardware annunciator panel designed to give infrastructure teams immediate, line-of-sight situational awareness when seconds count.
Merging a brilliant 4.0-inch multi-touch square IPS display with an integrated multi-protocol transactional processing core, the AP-400 serves as your primary physical outpost for tracking critical equipment health, completely independent of complex cloud dashboards or distributed software monitoring networks.
Absolute Data Integrity
Multi-Protocol Edge Reliability
Engineered for absolute data integrity, the AP-400 moves beyond standard "fire-and-forget" status tracking. Equipped with a versatile multi-protocol stack supporting SNMPv1, SNMPv2c, SNMPv3 (USM/VACM), and MQTT (with TLS 1.3), the panel natively receives and decodes autonomous site notifications from RTUs, telemetry hubs, and modern IoT brokers.
For SNMP streams, the panel immediately generates and returns application-layer acknowledgments (ACKs) via standard GetResponse protocols back to your telemetry hardware; for MQTT, it enforces verified QoS 1 message traversal. With an underlying memory matrix capable of holding up to 2,000 active concurrent faults across your network infrastructure, the AP-400 ensures that no critical event is dropped, hidden, or left unrecorded.
Urgency-Driven Optimization
Intelligent Visual Triage
The AP-400’s interface features an advanced, embedded layout designed to remove background operational noise and keep engineers focused on the highest risks. Utilizing a localized dynamic sorting engine, the panel continually evaluates multi-site telemetry data, automatically ranking faults and grouping them by network severity tiers.
An integrated, real-time triage scoring ribbon visually scales an outage's risk index as it ages, providing field teams with an immediate metric of technical urgency. Key operations are housed behind an elegant layout that blends deep slate backgrounds with high-contrast indicator bars and responsive touch controls, ensuring simple navigation even in low-light facility environments.
Site 4 - Power Grid Outage
enviroSENSOR 2 - Temp High (+42.5°C)
Node 0 - Battery Backup Mode
Flexible Network Topology
Decentralized Deployment & Remote Web Access
Because the AP-400 is engineered from the ground up as a native networked device, it breaks free from the physical constraints of traditional, point-to-point hardwired alarm boxes. It can be deployed seamlessly at any point in your network architecture where inbound IP traffic from your T:LAN RTUs, SNMP sources, or MQTT brokers can reach.
Dual-Layer Local Monitoring
This flexible routing logic enables a unique, dual-layer monitoring framework: you can position units locally within unmanned equipment shelters for immediate on-site diagnostics, while simultaneously dropping an identical unit onto an executive desk or a prominent console inside a central Network Operations Center (NOC).
Remote Access Web Interface with TLS
Beyond its physical touch panel, the AP-400 features an embedded Remote Access Web Interface with TLS security (HTTPS). System administrators and NOC engineers can securely view live alarm queues, configure telemetry endpoints, adjust audio alarm thresholds, and perform firmware maintenance from any standard browser across the enterprise network.
SPECS AT-A-GLANCE
Precision multi-protocol tracking and visualization optimized for local facility command.
Sleek Footprint, Easy Setup
Simplified Infrastructure Integration
Designed for seamless integration into enterprise IT and operational technology (OT) footprints, the AP-400 features a sleek, space-saving wedge chassis that fits naturally onto facility desktops or mounts securely to standard electrical wall enclosures.
Utilizing IEEE 802.3af Power-over-Ethernet (PoE), the panel draws all operational current and extracts 10/100 Mbps Fast Ethernet network telemetry over a single, clean CAT5 cable layout—minimizing deployment footprints and eliminating field power supplies. Backed by multi-protocol ingestion, a secure remote web interface, high-output internal audio alert speaker, and dynamic slider controls, it stands as a rugged, reliable tool for telecom central offices, data centers, and critical facility control points.
DEPLOYMENT ADVANTAGES
- ✓ Wedge Chassis Layout: Extremely compact footprint optimized for desktop line-of-sight visual angles or neat electrical wall-mount integration.
- ✓ Multi-Protocol Support: Ingest telemetry seamlessly from SNMPv1, SNMPv2c, cryptographic SNMPv3 (USM/VACM), and MQTT over TLS 1.3.
- ✓ Remote Access Web Interface: Embedded web interface with TLS security (HTTPS) for remote browser monitoring, triage management, and device configuration.
- ✓ Unified PoE Extraction: Zero secondary power supply cabling. Telemetry data and Class 2 PoE power travel together through a single CAT5 cable.
- ✓ Local Audio Beaconing: Integrated 2W high-output speaker emits distinctive audible warnings that demand rapid attention during critical alarms, adjustable on-screen slider controls.
Technical Specifications
PHYSICAL
- Dimensions (HxWxD):
- 89mm x 89mm x 54mm (Wedge-shaped chassis)
(3.5” x 3.5” x 2.1”) - Weight:
- 150g (0.33 lbs)
- Mounting:
- Wall mount or Desktop orientation
POWER
- Input Requirements:
- PoE IEEE 802.3af (Class 2 alternative power mapping)
- Power Consumption:
- 1.5W (Minimum / Idle) to 5.0W (Maximum audio/backlight load)
- Connector:
- Integrated into Ethernet jack (RJ45)
ENVIRONMENTAL
- Operating Temp:
- 0 °C to +50 °C (32 °F to 122 °F)
- Storage Temp:
- -20 °C to +70 °C (-4 °F to 158 °F)
- Humidity Limits:
- Up to 80% relative humidity (non-condensing)
INTERFACE & CONNECTIVITY
- Network Type:
- 10/100 Mbps Fast Ethernet Port with Native PoE Extraction
- Connector:
- Standard Shielded RJ45
- Recommended Wiring:
- Category 5 (CAT5e) or better twisted-pair cabling
- Remote Web Access:
- Embedded HTTPS Web Server with TLS Security
Alarms Processing & Protocols
- Protocols Support:
SNMPv1, SNMPv2c, SNMPv3 (USM / VACM AuthPriv), MQTT (v3.1.1 / v5.0 with TLS 1.3) - Remote Access Web Interface:
Embedded Web Interface with TLS Security (HTTPS) for remote triage & configuration - Transaction Core:
Automated SNMP GetResponse (ACK) Generation & MQTT QoS 1 Delivery Verification - Network Stack:
TCP/IP, UDP, IPv4, DHCP Client, SNTP Network Uptime Sync, TLS 1.3 Cryptographic Engine, HTTPS Server - Site Capacity:
Monitors up to 8 distinct T:LAN RTU Telemetry Nodes or MQTT broker telemetry streams - Alarm Capacity:
Tracks up to 250 active sub-zone alarms per individual site (2,000 active concurrent faults total) - Real-Time Filters:
Per-Severity Categorization (CRITICAL, MAJOR, MINOR, WARNING, INFO) - Sorting Engine:
Highest Severity Triage Core / Most Recent Active Stack Matrix - Triage Calculation:
Exponential risk score optimization (e.g. 1 x CRITICAL outage for 2h = 100% Urgency)
User Interface & Audio
- Display Technology:
- 4.0-Inch High-Fidelity IPS Capacitive Multi-Touch Screen Panel
- Display Resolution:
- 720 x 720 true pixels, Full 16-Bit Color Space
- UI Framework:
- High-Performance, Responsive Embedded UI Layout Engine + Secure Remote Web Interface
- Internal Speaker:
- 2W Internal Audio Speaker
ORDERING INFORMATION
| Product SKU | Description | Status |
|---|---|---|
| 1014-A011004A | Optima AP-400 Alarm Display Panel | Active |
IMPORTANT NOTE
Specifications subject to change without prior written notice. All referenced trade names are either trademarks or registered trademarks of their respective companies.DOCUMENTATION
AP-400 BROCHURE
Complete product brochure with wedge chassis dimensions, PoE power requirements, SNMPv1/v2/v3 and MQTT specifications, remote access web interface, and ordering details.
